TPA-3210A Triple Play Tester is a handheld tester testing the integrated network of data, audio and video. It supports VDSL2, ADSL/ADSL2/ADSL2+, 10/100M Ethernet test, IPTV, VoIP test, which ensure that it become an essential tool for Triple-play validation, maintenance and troubleshooting.
l xDSL Physical Layer Test
l xDSL Network Layer Test .
l xDSL Application Layer Test
l Ethernet Test
l IPTV Test
l VoIP Test
l Cable Test
l Others
l 7-inch color touch LED, graphical interface, easy-to-use.
l Test data, audio and video, includes IPTV and VoIP QoS test, video stream analysis, IP phone simulating and ADSL1/2/2+, VDSL2 and 10/100M Ethernet test.
l Test result Pass/Fail indicate, clarify all problem at a glance.
l Complete business validation test, include upstream and downstream rate, simulating modem, and set upper box, Ping test, etc.
l Copper circuit quality function, including DMM, impedance performance troubleshooting, longitudinal balance test, TDF test, which lead to decide circuit physical trouble.
l IPTV set top box simulation
l IPTV “set top box +Modem” simulation
l Modem simulation+ IPTV Pass Mode
l IPTV Pass Mode
l xDSL Modem simulation mode
l xDSL Modem simulation +NAT mode
l xDSL Modem Substitute mode
l xDSL access VoIP test mode
l LAN access VoIP test mode
|
General
|
|
Spec
|
210×146×58 (mm)
|
|
Weight
|
1350g
|
|
Screen
|
800x480resulution TFT color
|
|
Operation Mode
|
Touch
|
|
Interfaces
|
RJ11, RJ45, USB*2, SD, DB15, microphone port, earphone port, power supply.
|
|
Battery
|
Lithium battery
|
|
Charge Time
|
3 hours
|
|
Endurance Time
|
5 hours
|
|
Work Environment
|
Operation Temperature
|
-10℃~+50℃
|
|
Storage Temperature
|
-20℃~+70℃
|
|
Operation Humidity
|
10% ~ 90%
|
|
Storage Moisture
|
5% ~ 95%
|
|
Data Storage Capacity
|
Storage Capacity 100M (expandable), can store 2000+ test results.
|
|
xDSL Test interfaces xDSL
|
|
Circuit attenuation
|
0～63.5dB
|
|
Circuit output power
|
-32.0～31.5dBm
|
|
Circuit noise tolerance
|
-64.0～63.5dB
|
|
ADSL2+ Circuit downstream channel rate
|
0～24Mbps
|
|
ADSL2+ Circuit upstream channel rate
|
0～1.2Mbps
|
|
VDSL2 Circuit downstream channel rate
|
0～100Mbps
|
|
VDSL2 Circuit upstream channel rate
|
0～100Mbps
|
|
DMT modulated bits quantity on sub-channel
|
0～15
|
|
Circuit error(CRC, HEC, FEC) quantity
|
0～65535
|
|
test interface indicator-DMM
|
|
Loop circuit impedance
|
5Ω~5KΩ±5%
|
|
Electric capacity
|
0~3000nF±5%
|
|
DC voltage
|
-250V~250V±1%
|
|
AC voltage
|
0~250V±1%
|
|
Insulated impedance
|
0.1MΩ~99MΩ±5%
|
|
TDR test interface indicator-TDR
|
|
Pulse width
|
Minimum 10ns；200ns-32.6us，41.7ns step, tunable
|
|
V.O.P
|
120 - 299 m/us
|
|
Test length
|
3m-6000m
|
l Basic
|
Serial No.
|
ITEM/SPEC
|
REMARKS， Quantity（pcs）
|
|
1
|
TPA-3210A Triple Play Tester
|
TPA-3210A 1pcs
|
|
2
|
Touch pen
|
1pcs
|
|
3
|
Alligator clip test line（1.5m）
|
1pcs
|
|
4
|
RJ11 direct connection line（2m）
|
1pcs
|
|
5
|
crossover cable（1.5m）
|
1pcs
|
|
6
|
direct connection cable（1.5m）
|
1pcs
|
|
7
|
Power adaptor
|
1pcs
|
|
8
|
User manual
|
1pcs
|
|
9
|
Instrument package
|
1pcs
|
l Module
|
Serial No.
|
ITEM/SPEC
|
Remarks
|
|
TPA-3210A-ADSL2+
|
ADSL2+ Modem module
|
Optional, Module is matched in The Analyzer.
|
|
TPA-3210A-VDSL2
|
VDSL2 Modem module
|
l Optional
|
Serial No.
|
ITEM/SPEC
|
Remarks
|
|
USBMOUSE
|
USB interface mouse
|
|
|
SDCARD
|
SD card
|
capacity 1G~4G
|
|
USBDISK
|
USB memory discs
|
capacity 1G~4G
|
